Polaroid 636AF User Manual

TROUBLESHOOTING CHARTS
(NOTE: Also see the RIB and Product Alert listing following these charts)
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
Dark Slide Cycle 1.Door pawl spring defec- 1. Replace spring
with Front Door Open tive or not loaded or load spring
(Non-Continuous) (If under pack pawl. properly.
cycling continuously
go to Continuous 2.S1 slider fingers and 2. Disassemble and
Cycling chart) switches on contact install properly
support block not
interfaced properly.
3. S1 switch contacts 3. Re-form S1 contacts
deformed. (Closed with if possible. Replace
front door open - check contact support
with meter). block if necessary.
4.Contact support block 4. Replace contact
defective. support block.
No Dark Slide Cycle 1. S9 switch open (check 1. Re-form S-9 switch
with meter). contacts. Replace
support block if
necessary.
2. S1 slider fingers and 2. Disassemble and
switches on contact install properly.
support block not
interfaced properly.
3. S1 slider cam not mated 3. Disassemble and
to counter properly. install properly.
4. S1 switch contacts 4. Re-form S1 contacts
deformed (closed with if possible. Replace
front door open - check contact support
with meter). block if necessary.
5. Contact support block 5. Replace contact
defective. support block.
6. Battery (+) wire not 6. Install battery wire
trapped in contact properly.
support block properly.
7. Flex circuit motor 7. Install flex motor
contacts not seated contacts properly.
properly.
8. Counter spring defective 8. Repair or replace
or not loaded properly. spring.
79
