1 FILTER PUMP POWER INFORMATION
2 PART LIST
3 FILTER PUMP INSTALLATION
FILTER PUMP MODEL WATTAGE AMPERAGE
CP2000-C Filter System Pump 340 watts 2.8 amps
Item
1 Fitting Gasket 1
1
1
1
1
1
1
1
1
1
1
1
1
4
2
1
1
1
1
1
1
1
4
Suction Fitting
Suction Fitting Washer (SF Washer)
Fitting Lock Nut
Suction Fitting Cap (SF CAP)
Return Fitting
Return Fitting Diverter (RF Diverter)
RF Locking Ring
RF elbow 90˚
RF nut
RF Gasket
RF Thrust Washer
Hose
Hose Clamp
Filter Pump Assembly
Vent Screw
Vent Screw O-Ring
Seal Top
Canister Gasket
Type D Filter Cartridge
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
O-Ring (on hose connections)
20
GFCI Power Cord Set
22
Return Fitting plug (RF Plug)
23
Part Name Qty
Set up the pool by following all instructions comes
with the pool. Do not fill water until the Filter Pump
is properly installed. Locate the outlet and inlet
openings on the pool wall.
1
Install the Suction Fitting on the outlet opening of
the pool.
2
Install the Return Fitting on the inlet opening of the
pool.
3
Remove the Filter Pump(15), Hoses (13) and Hose
Clamps (14) from the package.
4
Attach one hose to the Suction Fitting and the Filter
Pump inlet.
5
Attach the hose to the pool return fitting and the
pump outlet.
6
5
20
2
1
3
4
7
8
6
11
9
20
10
12
14
13
16
17
18
21
19
15
20
15
22
13
14
7
8
6
9
11
12
10
4
3
1
2
23
Inlet
Outlet
RETURN
FITTING
SUCTION
FITTING
POOL
RETURN
FITTING
POOL
SUCTION
FITTING
20
13
14
13
14
