11
Model: Rfg = Refrigerating Only
Rfg / Htg = Refrigerating & Heating
Turbine Pump (“T” Series Chillers)
Model T Series Chillers Rfg Rfg / Htg Rfg Rfg / Htg
Operating Temperature -10° to 40°C -10° to 70°C -10° to 40°C -10° to 70°C
Compressor 3/4 HP 1 HP
Cooling Capacity @ 20°C
10°C
0°C
2500 watts 8525 BTU/hr
1700 watts 5797 BTU/hr
760 watts 2591 BTU/hr
2900 watts 9889 BTU/hr
1950 watts 6649 BTU/hr
1000 watts 3410 BTU/hr
Flow Rate @ 0 psi 3.5 gpm / 13.2 lpm 3.5 gpm / 13.2 lpm
Pump Pressure (adjustable)
20 to 90 psi
138 to 621 kPa
20 to 90 psi
138 to 621 kPa
Reservoir Capacity 1.1 gal / 4.2 liters 1.1 gal / 4.2 liters
Shipping Weight
197 pounds
89 kg
199 pounds
90 kg
208-230 V, 60 Hz
Volts Range
187 to 253V
Amps 11.9A 12.2A 12.2A 12.5A
240 V, 50 Hz
Volts Range
Over Voltage
198 to 264V
Category II
Amps 11.9A 12.2A 12.2A 12.5A
Specifications subject to change without notice.
Notes: Refer to the serial number plate on the rear of the Chiller for model and electrical data.
Cooling capacity (watts x 3.41) = BTU/hour. Performance specifications determined at ambient temperature of 20°C (68°F).
For 50Hz models, derate cooling capacity 17%.
Positive Displacement Pump Models: External pressure reducing assembly (Cat. No. 060302) steps down high outlet
pressure to 10 to 45psi.
Environmental Conditions Indoor use only
Maximum Altitude: 2000 meter
Operating Ambient: 5° to 30°C
Relative Humidity: 80% for temperatures to 30°C
Pollution Degree: 2
Class 1: Residential, Commercial, Light Industrial
Class 2: Heavy Industrial
