PROEL HPX2800 User Manual

4
TechnicalSpecification
MODEL HPX900 HPX1200 HPX2400 HPX2800
Power8ohm* 200W 300W450W 600W
Power4ohm* 300W 450W800W 1000W
Power2ohm** 450W 600W 1200W 1400W
PowerBRIDGE8ohm* 400W 600W900W 1200W
PowerBRIDGE4ohm** 900W 1200W 2400W 2800W
OutputStage ClassAB ClassAB ClassHClassH
Frequencyresponse
(+0/‐0.5d
B
20Hz‐20KHz 20Hz‐20KHz 20Hz‐20KHz 20Hz‐20KHz
InputSensitivity(nominal) +2.3dBu/1.0Vrms +1.0dBu/0.87Vrms +0.8dBu/0.85Vrms 0dBu/0.775Vrms
InputSensitivity(fixedgain) +8.3dBu/2.02Vrms +4.0dBu/1.23Vrms +5.8dBu/1.51Vrms +7.0dBu/1.73Vrms
GAIN(nominal/fixed) 32dB(40x)/26dB(20x) 35dB(56x)/32dB(40x) 37dB(71x)/32dB(40x) 39dB(89x)/32dB(40x)
InputConnectors XLRM,1/4"JACK,RCA XLRM,1/4"JACK,RCA XLRM,1/4"JACK,RCA XLRM,1/4"JACK,RCA
Impedance 20Kohm(balanced)
10Kohm(unbalanced)
20
Kohm(balanced)
10Kohm(unbalanced)
20Kohm(balanced)
10Kohm(unbalanced)
20Kohm(balanced)
10Kohm(unbalanced)
OutputConnectors SPEAKONandBindingPost SPEAKONandBindingPost SPEAKONandBindingPost SPEAKONandBindingPost
DampingFactor >100 >100 >200 >200
SlewRate >20V/uS >20V/uS >20V/uS >20V/uS
S/NRatio(unweighted) >85dB >86
dB >90dB >91dB
THD+N <0.1% <0.1% <0.1% <0.1%
Controls INPUTLEVEL,INPUTSENSITIVITY,
STEREO/BRIDGE/PARALLEL,
LOWPASSNOTCH(LPN),GND
INPUTLEVEL,INPUTSENSITIVITY,
STEREO/BRIDGE/PARALLEL,
LOWPASSNOTCH(LPN),GND
INPUTLEVEL,INPUTSENSITIVITY,
STEREO/BRIDGE/PARALLEL,
LOWPASSNOTCH(LPN),GND
INPUTLEVEL,INPUTSENSITIVITY,
STEREO/BRIDGE/PARALLEL,
LOWPASSNOTCH(LPN),GND
LEDIndicators POWER,
ON,PARALLEL,
BRIDGE,
POWER,ON,PARALLEL,
BRIDGE,
POWER,ON,PARALLEL,
BRIDGE,
POWER,ON,PARALLEL,
BRIDGE,
Cooling VariablespeedDCfan VariablespeedDCfan VariablespeedDCfan VariablespeedDCfan
Protections AClowpower,DC,thermal,
shortcircuit,VHF,CLIPlimiter
AClowpower,DC,thermal,
shortcircuit,VHF,CLIPlimiter
AClowpower,DC,thermal,
shortcircuit,
VHF,CLIPlimiter
AClowpower,DC,thermal,
shortcircuit,VHF,CLIPlimiter
MainsSupplyVoltage 230VAC(±10%)50/60Hzor
120VAC(±10%)50/60Hz
230VAC(±10%)50/60Hzor
120VAC(±10%)50/60Hz
230VAC(±10%)50/60Hzor
120VAC(±10%)50/60Hz
230VAC(±10%)50/60Hzor
120VAC(±10%)50/60Hz
MaximumConsumption 1450VA 1850VA 3550VA 4120VA
RatedConsumption*** 200VA 250VA 450VA 600VA
StandbyConsumption 50VA 65VA 65VA 65VA
Dimensions(WxHxD) 483x89x335mm
19"x3.5"x13.2"(2Urack)
483x89x395mm
19"x3.5"x15.6"(2Urack)
483x
89x395mm
19"x3.5"x15.6"(2Urack)
483x89x395mm
19"x3.5"x15.6"(2Urack)
Weight 6Kg(13.2lb) 6.9Kg(15.2lb) 9.2Kg(20.3lb) 9.2Kg(20.3lb)
*RMSbothchannelTHD<1%
**40msburst
***Ratedconsumptionismeasuredwith
pinknoisewithacrestfactorof12dB,thiscanbeconsideredastandardmusicprogram.


PROEL HPX2800 Specifications

General

Brand	PROEL
Model	HPX2800
Category	Amplifier
Language	English
