ProForm SMART STRIDER User Manual

5
M10 Locknut
(81)–2
M8 Jam Nut
(79)–7
M8 Washer
(88)–6
Wave Washer
(111)–2
M8 Split
Washer
(90)–3
M4 x 16mm
Round Head
Screw (101)–10
M4 x 32mm
Round Head
Screw (105)–6
M8 x 69mm Bolt (80)–1
M4 Split
Washer
(112)–8
M4
Washer
(102)–8
M4 x 50mm Screw
(108)–2
M4 x 16mm
Blunt Screw
(104)–8
M10 x 80mm Carriage Bolt (82)–2
Hub Screw
(87)–8
M8 x 23mm
Shoulder
Screw (115)–4
M8 x 23mm
Screw (84)–4
M8 x 41mm
Bolt (78)–4
M8 x 80mm Bolt (116)–2
M10 x 127mm Screw (83)–2
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
