Matrix 6/816 Installation Manual
Page 32 RINS546-10
4.1.2 Matrix 816
ZONES
POWER SUPPLY
Number of programmable zones – 8, expandable to 16 Power input – 17V AC
Zone loop types – Normally Closed, Normally Open, Low voltage output
–
13.8V DC regulated
SEOL, DEOL Max. capacity power output (incl. panel)
–
1.25A
Zone loop current – 0.5mA max. Max. power for ext. devices (excl. battery)
–
0.6A
Zone loop timers – 0.3sec (normal zones)
30 ms (Fast Zones)
TRANSFORMER REQUIRED
Zone wire resistance – not more than 470Ohm For 230VAC, Primary – 230VAC, 50Hz, 20W min.
PGM OUTPUTS
Secondary – 17VAC, 1.25A
Number of programmable outputs – 7 For 120VAC, Primary – 120VAC, 50Hz, 50W min.
Output types – up to 36 for PGMs1-6, 37 for PGM7 Secondary – 16.5VAC, 40VA
PGM1 – Relay Contacts, 30V DC @ 3A
PGM2 – Transistor Open Collector, 200mA
CURRENT CONSUMPTION
PGM3 – Transistor Open Collector, 200mA Matrix 816 PCB (alone) – 60mA
PGM4 – Transistor Open Collector, 500mA Remote keypad MX-ICON – 50mA
PGM5 – Transistor Open Collector, 200mA On-board expander – 1mA
PGM6 – Transistor Open Collector, 200mA
BATTERY
Siren – Transistor Open Collector, 500mA Type – Lead Acid rechargeable
DIGITAL COMMUNICATOR
Battery Charge commencing
– min. 5.5V
Digital communicator
–
Analogue line Battery Capacity
–
2.8A/h … 7.2A/h
Lightning protection – 6.75kV/125Amps Protection on BAT terminals – short & reverse
Low Battery Cut-Off – 10.4V
MECHANICAL
FUSE CONTROL
Dimension – 340 х 280 х 101mm AC input – 2A (quick blow F1L)
Material & colour – Metal / White Polymer Auxiliary supply output
–
1A (quick blow F1L)
RKP supply output
–
1A (quick blow F1L)
ENVIROMENTAL
Battery Input – 5A (slow blow T5H)
Operation temperature: 0 to +40
C
Storage temperature: –20 to +40
C
NOTE: The battery charging voltage is microprocessor controlled and switched on or off as
needed. In order to measure this voltage the battery MUST be connected, otherwise a false
voltage will be measured.
When all parts are working normally, this equipment in combination with the PSTN and suitable ARC
equipment will meet the requirements of ATS2.
This product is suitable for use in systems designed to comply with
PD6662:2010 at Security Grade 2 and Environmental Class 2
