Manual for Advance 6T series
Introduction
Onboard IDE
##
##
#" Supports two PCI PIO and Bus Master IDE ports
##
##
#
""
""
"Two fast IDE interfaces supporting up to four IDE devices including IDE hard disks
and CDROM drives
##
##
#
""
""
"Supports up to mode 4 timing
##
##
#
""
""
"Supports Ultra DMA33/66/100
Onboard I/O
##
##
#
""
""
"One floppy port supporting up to two 3.5 or 5.25 floppy drives with 360K/720K/
1.2M/1.44M/2.88M format
##
##
#
""
""
"Two high speed 16550 fast compatible UARTs(COM1/COM2/COM3/COM4
selective) with 16-byte transmit/receiver FIFOs(UART2 is optional)
##
##
#
""
""
"One enabled parallel port at the I/O address 378H/278H/3BCH with additional
bidirection I/O capability and multi-mode as SPP/EPP/ECP (IEEE 1284 compliant)
##
##
#
""
""
"Supports PS/2 mouse and PS/2 keyboard
##
##
#
""
""
"Provides four USB ports
##
##
#
""
""
"Supports LS-120 floppy disk drive and Zip drive
##
##
#
""
""
"All I/O ports can be enabled/disabled in the BIOS setup
Onboard Audio
##
##
#
""
""
"Standard AC97 Codec interface
Onboard AGP
##
##
#
""
""
"Supports AGP 4x
##
##
#
""
""
"Integrated 2D/3D Graphics Controller
##
##
#
""
""
"Supports 2~ 8Mbytes of Frame Buffer
Onboard LAN( optional )
##
##
#
""
""
"Provides One 10/100M LAN interface
##
##
#
""
""
"10/100 Mbit/sec Ethernet support
Advanced Features
##
##
#
""
""
"PCI- 2.2 compliant
##
##
#
""
""
"Provides Trend ChipAwayVirus® On Guard
##
##
#
""
""
"Supports wake-up on LAN
##
##
#
""
""
"Supports wake-up on internal/external modem
##
##
#
""
""
"Supports system monitoring (monitors system temperature, CPU temperature, voltages
and fan speed)
