QDI Superb 4 Series User Manual

Manual for S4 series
Chapter 3
l SIS-7013 S/W Enabled Enable CNR AC97 Modem.
Modem Disabled Disable CNR AC97 Modem.
l SIS-900 Enabled The onboard LAN is enabled.
10/100M ETHERNET Disable The onboard LAN is disabled.
l System Share 4/8/16 MB Set the display memory as 6/8/16/32/64MB.
Memory Size 32/64 MB
l Onboard Super IO Press Enter Press enter to set Super IO device.
Device
l Onboard FDC Enabled Onboard floppy disk controller is enabled.
Controller Disabled Onboard floppy disk controller is disabled.
l Onboard 3F8/IRQ4, Define the onboard serial port address and
Serial Port 1/2 2F8/IRQ3, required interrupt number.
3E8/IRQ4,
2E8/IRQ3,
Auto Onboard serial port address and IRQ are
automatically assigned.
Disabled Onboard serial port is disabled.
l UART Mode Normal Defines Serial Port as standard serial port.
Select IrDA Supports IRDA mode.
ASK IR Supports SHARP ASK-IR protocol with maximum
baud rate up to 57600bps.
l UR2 Duplex Mode Half Default is recommended.
Full
l Onboard Parallel 378/IRQ7 Define parallel port address and IRQ channel.
Port 278/IRQ5
3BC/IRQ7
Disabled Onboard parallel port is disabled.
l Parallel Port SPP Define the parallel port mode
Mode EPP
ECP
ECP+EPP
Item Option Description
