QNAP TS-h973AX User Manual

Note
It may take a couple of minutes to complete QuTS hero installation.
18. Optional: Click Go to NAS Management.
Tip
Click Go to NAS Management to set more advanced QuTS hero configurations and settings.
For details, see QuTS hero User Guide.
Installing QuTS hero Using the Cloud Key
Warning
Installing QuTS hero deletes all data on the drives. Back up your data before proceeding.
Note
You can revert to QTS operating system anytime. For details, see QuTS hero user guide.
1. Power on the device.
2. Connect the device to the internet.
3. Go to the QNAP Cloud Installation page using one of the following methods:
• On your computer, go to http://install.qnap.com/.
• Scan the QR code on the NAS using a mobile device.
The web page lists all the uninitialized QNAP NAS devices on the local network.
4. Locate the NAS in the list and then click Initialize.
Note
If your NAS is not listed, follow the instructions on the web page to specify the Cloud Key on the
NAS.
The installation wizard opens in the default web browser.
5. Create an account or sign in to myQNAPcloud.
Note
You must return to this page to complete the installation after creating an account.
6. Specify the myQNAPcloud device name for the NAS.
Note
• The myQNAPcloud device name is used when remotely accessing the NAS.
• For security purposes, the myQNAPCloud Link remote connection service will be disabled
on your NAS after initialization. You can enable it by connecting to QuTS hero through LAN
and then installing myQNAPCloud Link.
7. Click Next.
The Smart Installation Guide opens in the default web browser.
8. Perform any of the following actions.
TS-h973AX User Guide
Installation and Configuration 32

QNAP TS-h973AX Specifications

General

RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
RAID support	Yes
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	9
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Processor cores	4
Processor model	V1500B
Processor family	Ryzen Embedded
Processor frequency	2.2 GHz
Processor manufacturer	AMD
Operating system version	h5.0.0
Operating system installed	QuTS hero
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Type	NAS
Device class	Home & Home Office
Share folder	AFP, CIFS/SMB, FTP, WebDAV
Backup features	Cloud, iSCSI LUN
Number of users	2000 user(s)
Browser supported	Safari, Chrome, Internet Explorer, Firefox
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Flash memory	5000 MB
Memory slots	2
Internal memory	8 GB
Memory form factor	SO-DIMM
Internal memory type	DDR4
Maximum RAM supported	64 GB
Fan voltage	12 V
AC input voltage	100 - 240 V
Power supply location	External
Number of power supply units	1
Power consumption (HDD standby)	41.2 W
Power supply unit (PSU) capacity	120 W
Ethernet LAN data rates	100, 1000, 2500, 5000, 10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
Ethernet LAN (RJ-45) ports	3
Cables included	AC, LAN (RJ-45)
Number of screws	56
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Chassis type	Tower
Cooling type	Active
Fan diameter	140 mm
Product color	Black
LED indicators	HDD, LAN, Power, SSD, Status, USB
Number of fans	1 fan(s)
Cable lock slot type	Kensington

Weight and Dimensions

Depth	224.1 mm
Width	224.6 mm
Height	182.65 mm
