QTech QSW-8200 series User Manual

User Manual
Chapter 2. Hardware Installation 26
www.qtech.ru
2.3.3 SFP Transceiver Installation
QSW-8200 series provide multiple 1000Mb SFP transceiver slots.
The procedure for installing the SFP transceiver is shown below:
Step 1: Put on a ESD wrist strap (or antistatic gloves).
Step 2: Insert the SFP transceiver to the guide rail inside the fiber interface line card. Do not
put the SFP transceiver up-side-down.
Step 3: Push the SFP transceiver along the guide rail gently until you feel the transceiver snap
into place at the bottom of the line card.
Note: the SFP transceiver is hot swappable.
Caution!
Do not stare directly at the 2 fiber bore in the SFP transceiver when the switch is in operation,
otherwise the laser may hurt your eyes.
2.3.4 QSW-2SFP+ extended module Installation
QSW-8200 series provide 10Gb slots. The procedure for installing the QSW-2SFP+ module and
the SFP+ 10Gb fiber transceiver is shown below:
Step 1: Put on an ESD wrist strap (or antistatic gloves).
Step 2: Insert the QSW-2SFP+ module to the guide rail inside the 10Gb module slot.
Step 3: Push the QSW-2SFP+ module along the guide rail gently until it comes into contact with
the machine panel.
Step 4: Insert the SFP+ transceiver to the guide rail inside the QSW-2SFP+. Do not put the SFP+
transceiver up-side-down.
Step 5: Push the SFP+ transceiver along the guide rail gently until it comes into contact with the
QSW-2SFP+.
Note: the 2SFP+ extended module does not support hot swappable. QSW-2SFP+ extended
module can insert SFP+ fiber transceiver.
2.3.5 QSW-2GB Extended module Installation
QSW-8200 series provide 10Gb slots. The procedure for installing the QSW-2GB module and
the SFP 1Gb fiber transceiver is shown below:
Step 1: Put on an ESD wrist strap (or antistatic gloves).
