Quantum Superloader 3 Quick Start Guide

Rack Mounting the Autoloader 9
SuperLoader 3
Figure 4 Attaching Support
Brackets
4 With the help of a second installer, insert the autoloader into the rack so that the
autoloader brackets slide into corresponding support brackets on the rear rails and
the tabs at the front of the autoloader align flush with the clip nuts on the front rails
(see figure 5
).
Caution: Do not release the front end of the autoloader until it can be secured to
the rack.
Support bracket
Rack screws
Clip nuts
Rear rail in rack
Outer cover of rack
