EC20 Mini PCIe Hardware Design
EC20_Mini_PCIe_Hardware_Design Confidential / Released 32 / 36
5 Mechanical Dimensions
5.1. General Description
This chapter mainly describes the following dimensions of EC20 Mini PCIe:
 Mechanical Dimensions of EC20 Mini PCIe
 Standard Dimensions of Mini PCI Express
 Packaging
5.2. Mechanical Dimensions of EC20 Mini PCIe
Figure 16: Mechanical Dimensions of EC20 Mini PCIe (Unit: mm)
