2 Quectel NMEA Packet Protocol
This chapter introduces the Quectel NMEA packet protocol which is a set of extension messages of the
standard NMEA packet protocol. These messages are used to control and configure Quectel L70, L80,
L76, L76-L, L86 and L26 modules.
The structure of Quectel NMEA packet is shown as below:
2.1. Quectel NMEA Packet Format
Packet Contents:
Preamble: One byte character.
‘$’
TalkerID: Two bytes character string.
“PQ“
PktType: 1-10 bytes character string.
An identifier used to tell the decoder how to decode the packet.
DataField: The DataFileld has variable lengths depending on the packet type.
A command symbol ‘,’ must be inserted ahead of each data filed to help the decoder
process the DataField.
* : 1 byte character.
The star symbol is used to mark the end of DataField.
CHK1, CHK2: Two bytes character string.
CHK1 and CHK2 are the check sum of the data between Preamble and ‘*’.
CR, LF: Two bytes binary data.
The two bytes are used to identify the end of a packet.
The maximum length of each packet is restricted to 255 bytes.
