GNSS Module
L76
EVB
U
ser
Guide
L76_
EVB
_User Guide
Confidenti
al / Rele
ased
11
/
25
3.2.
UART Interface
Figure
5
:
UA
RT
Interface
Table 1: Pins
of UA
RT port
Pin
Signal
I/O
Descriptio
n
2
RXD
I
Receive dat
a
3
TXD
O
T
rans
mit dat
a
5
GND
GND
Quectel
Confidential
11
13
Table of Contents
