GNSS Module Series
L80&L80-R&L86&LC86L EVB User Guide
L80&L80-R&L86&LC86L_EVB_User_Guide 20 / 30
5 Using PowerGPS
In this chapter, you can find out how to use PowerGPS, a tool for checking the status of GNSS receivers,
when you are working with your EVB.
5.1. COM and Baud Rate Setting
Step 1: After EVB accessories are assembled, turn on the EVB and start PowerGPS (PowerGPS Trial
2.3.5 is used as an illustration in this document). After the tool is started, the following interface is
displayed with 6 default windows.
Figure 12: PowerGPS Interface (Not Connected)
Step 2: At the bottom of the interface, select a correct COM port and baud rate (the modules support
9600 bps by default), then click the button “Create Connection”. The following interface is
shown when the module is connected.
