Quick MILL Monza Deluxe User Manual

Monza Deluxe Super Automatic Espresso Machine
3
3
 The steam boiler is equipped with a
pressure relief valve calibrated at 2.5 bar
and a resettable hi-limit switch that
interrupts heating in the event of a fault.
 The heat exchanger is equipped with an
expansion valve calibrated to 9 bars for
brewing espresso.
 The coffee group heater is equipped with
an electronic temperature control and is
protected by a safety thermal fuse to
prevent overheating.
 The pump is equipped with an automatic
resettable thermal protector in case of
overheating.
 All heating elements subject to electric
current are situated inside the machine
housing.
Dimensions
L 14.75” x W 17.5” x H 17.5”
Weight
63 lbs.
Voltage
Power
Current
110-120V /50-60 Hz
1600 W
14 A
Water tank capacity 3 lt
Working temperature +40° to +113° F
 Packaging materials such as (plastic
bags, expanded polystyrene, nails,
boxes etc.) are a potential hazard and
must not be left within reach of children.
 Before plugging in the machine ensure
that the outlet voltage is 110Volts. A
resettable GFI outlet is recommended,
but not necessary.
 The power cord should be fully extended
(avoid kinking or compressing) in a
position where it cannot be knocked or
tampered with by children; it should not
be placed near water or other liquids or
heat sources, it should not be damaged.
If necessary, have it replaced by a
qualified electrician.
 The use of adaptors, multi-sockets or
extension cords is not recommended.
 In case of doubt or uncertainty, have a
qualified electrician check the electrical
system, which should be in accordance
with local safety regulations in force,
including:
- The appliance must have an Earth
grounded outlet.
- Electrical wire sufficient for the power
rating.
- Efficient circuit breaker.
 Place the machine on a water-repellant
surface (laminated, steel, ceramic etc.)
away from heat sources (ovens,
fireplaces etc.) and in an environment
where the tempture does not go below
40°F.
