Quicksilver 675SD — System & Component Overview and Operaon
16
Fresh Water
3. Bilge Pumps
Your vessel is equipped with two bilge pumps, with one located in the a secon of the boat, and the
second one located in the forward part of the boat. Access to the a bilge pump is via the motorwell
access plate, while access to the forward bilge pump is through a hatch located in the interior oor
liner. Both bilge pumps are rated for 500 GPH, and are acvated automacally by a built in mercury
free oat switch when the water in the bilge reaches a predetermined level. You can also manually
operate the bilge pump at the console by pressing the bilge pump switch.
Inspect the bilge pump intakes and keep them free of dirt or material which may impede the ow of
water through the pump. To clean the pump strainer, depress the lock tabs on both sides of the pump
and li the pump motor.
If water does not come out of the discharge hose:
1. Remove the motor module to see if the impeller rotates with the power on.
2. Remove any debris that may have accumulated in the nozzle secon or strainer base.
3. Check hose and connecon on hull side for debris and proper connecons.
4. If water ever entered the forward part of the bilge, the water can sll be evacuated by the
bilge pump.
Water pump
Water pump distribuon hose
Transom shower hose
Transom shower
Water tank ll
Water tank vent
Water tank vent hose
Water tank ll hose
Water tank
Water tank to water pump hose
Water pump lter
