QVM 9 Series 40
 Models : QVM9-090/125/150W1-NG
(UNIT : mm)
No Part Code Part Name Q’ty Material Remarks
1 C21701155A BBR15012041 Front Cover 1 SCP1 QVM9-090/125W1
C21701221A BBR15012042 〃 1 SCP1 QVM9-150W1
2 C21701340A BBK05011024 Cabinet 1 SCP1 QVM9-090/125W1, 0.8T
C21701341A BBK05011025 〃 1 SCP1 QVM9-150W1, 0.8T
3 C21750164A BH2505188A Base Bracket 2 SBHG1 All QVM9
4 C20109029B BH2505012A Flue Exhaust 1 STS All QVM9
5 C21606016B BH2423034A Flue Exhaust Packing 1 EPDM All QVM9
6 C21701216A BH2505055A Combustion Air Intake 1 PP All QVM9
7 C21701217A BH2505062A Combustion Air Intake Plate 1 PP All QVM9
8 C22203009A BH1419007A High Limit Fuse 1 All QVM9, Fuse Type
9 C21605023A BH2405002A Adiabatic Plate 1 AL+CERAMIC QVM9-090/125W1, 2T
C21601042A BH2405001A 〃 1 AL+CERAMIC QVM9-150W1, 2T
10 C21014139E NACR1GS20602 Main Controller 1 All QVM9, KDC-206-3M V1.4
11 C22601008A BH3101003A Expansion Tank 1 QVM9-090/125W1
C22602020A BH3102010A 〃 1 QVM9-150W1
12 C21708271A BH2507155A Heat Exchanger Inlet Pipe 1 C1220T QVM9-090W1
C21708274A BH2507156A 〃 1 C1220T QVM9-125W1
C21708311A BH2507157A 〃 1 C1220T QVM9-150W1
13 C21213011A BH1409002A Heating Flow Sensor 1 NYLON 66 All QVM9, φ20
14 C21708267A BH2507152A Air Vent Outlet Pipe 1 C1220T All QVM9
15 C20501022A BH1101014A Circulation Pump Assembly 1 All QVM9, CS-0125V, 115V/60Hz
16 C20313022A BH0902015A 3-Way Valve 1 All QVM9, A3-18-223A, 115V/50/60Hz
17 C21708253B BH2507087A Heating Supply Connection 1 C3712 All QVM9
18 C21708275A BH2507154A Air Vent Outlet Connection 1 C3712 All QVM9
19 C20301006D BH2507004A Heating Air Vent 1 All QVM9
20 C21708268A BH2507143A Air Vent Inlet Pipe 1 C1220T All QVM9
21 C20901011B BH1301010A Heating Strainer 1 All QVM9
22 C21708255B BH2507097A Heating Return Connection 1 C3712 All QVM9
23 C20307017A BH0905006A Pressure Relief Valve 1 All QVM9
24 C21899001C BH2501224A Siphon 1 PE All QVM9
25 C21708261A BH2507081A Heating Outlet Pipe 1 C1220T All QVM9
26 C40306019B BBXCC087008 Fan Assembly 1 AL QVM9-125/150W1, Without Air Filter
C40306022B BBXCC087009 Fan Assembly 1 AL QVM9-090W1, Including Air Filter
27 C21707120C BH2501200A Orifice 1 STS QVM9-090W1, LNG, φ27.4
C21707123C BH2501203A 〃 1 STS QVM9-125W1, LNG, φ29.5
C21707199B BH2501204A 〃 1 STS QVM9-150W1, LNG, φ28.5
28 C21707114B BH2501170A Mixing Chamber Assembly 1 ALDC QVM9-090W1
C21707115B BH2501171A 〃 1 ALDC QVM9-125W1
C21707146B BH2501172A 〃 1 ALDC QVM9-150W1
29 C21750162A BH2501221A Mixing Chamber Bracket 1 SBHG1 QVM9-090/125W1
C21750168A BH2501220A 〃 1 SBHG1 QVM9-150W1
30 C21707116B BH2501114A Nozzle 1 C3712 QVM9-090W1, LNG, φ5.95
C21707118B BH2501116A 〃 1 C3712 QVM9-125W1, LNG, φ6.60
C21707197A BH2501118A 〃 1 C3712 QVM9-150W1, LNG, φ6.30
31 C21605026A BH2405006A Mixing Chamber Packing 1 CERAMIC QVM9-090W1, 5T
C21605028A BH2405007A 〃 1 CERAMIC QVM9-125W1, 5T
C21605040A BH2405008A 〃 1 CERAMIC QVM9-150W1, 5T
32 C40306016A BBXCC088001 Burner Assembly 1 Metal Fiber QVM9-090W1, 150 X 100
C40306018A BBXCC088002 〃 1 Metal Fiber QVM9-125W1, 200 X 100
C40306024A BBXCC088003 〃 1 Metal Fiber QVM9-150W1, 200 X 133
33 C21002008A BH1401007A High Limit Sensor 1 All QVM9, MS-1P, Manual, Bi-Metal Type
34 C20701079A BH1201004A Ignition Transformer 1 All QVM9, DK-304, 115V/50/60Hz
35 C21002016A BH1401004A High Limit Sensor 1 All QVM9, MS-1P, Automatic, Bi-Metal Type
36 Flame Observation Port 1 MICA All QVM9
Parts List
