Email:
Voice:
Fax:
information@quincylab.com
800-482-4328
773-622-2282
Quincy Lab, Inc.
1925 N. Leamington Ave.
Chicago, Illinois 60639
Limited Warranty
Maintenance / Control Calibration / Cleaning Procedures
Troubleshooting Tips / Parts & Equiptment / Technical Support
Common Replacement Components Common Additional Equipment
Hydraulic Thermostat
Blower Motor
Door Ball Catch
Additional Shelf
Additional Shelf Rail
Exhaust Chamber Adapter
Floor Oven Stand
Storage Cabinet
Contact Quincy Lab techincal support for further assistance or visit us on the web at
www.quincylab.com
Technical Support
For a complete list of replacement components, part and additional
equipment, visit us on the web at www.quincylab.com or contact your
dealer for availability and pricing.
PART # 101-2223
PART # 301-2235 (115 VOLT)
PART # 301-2230 (230 VOLT)
PART # 301-2221
PART # 301-5000 PART # 301-2060
PART #301-2055
PART # 301-5001
PART # 301-5001S
(STAINLESS STEEL)
PART # 301-2065
The Bench Series Ovens are designed to be virtually maintenance free. But operational safety requires periodic clean-
ing and chamber temperature accuracy verification.
CLEANING PROCEDURE
CONTROL CALIBRATION
Twice a year, check the actual oven chamber temperature against a known accurate temperature measurement
device. Maintain temperature accuracy to within 20°F of the dial setting. (see Control Calibration on page 4.) Temperature
drift or frequent calibration is a sign that the thermostat is failing - replace thermostat upon early observation of
temperature instability.
Periodically check the rear air intake vents for dirt or dust build-up. Keep the intake & exit ports clear of obstruction
and clean of dust and dirt. This will keep the motor from overheating and reduce risk of fire. It may be necessary to remove
the rear electrical cover to clean or vacuum dirt and dust from in & around the motor. Unplug the oven before
removing the rear cover. To clean exterior and interior surfaces, use a damp cloth or an all-purpose cleaner. Avoid com-
mercially available oven cleaners.
PAGE 6
Unit not turning ON
when switch is in the
ON position
1. Check if unit tripped a GCFI outlet or fuse. Try a different
power outlet connection before moving to number 2 on this list.
2. Reset Thermal Safety disc in the back of the unit. (see PG 4
for more information)
3. Check wire connections and make sure there are no lose or
diconnected wires in the unit.
Unit’s temperature
varies by ± 15°F or
more
1. Check if motor is running continusly. If blower is working and
unit still has a wild varying temperature in any direction, or the
oven continous to heat and trips the Thermal Safety Disc,
thermostat may need to be replaced. Contact Quincy Lab for
further assitance.
Unit keeps tripping
GFCI or fuse
1. Bad GCFI outlet
2. Moisture on Heat Elements
1. No power going to the unit
2. Triggered Thermal Safety Disc
3. Disconneted / lose wires.
1. After setting a Temperature, it
varies widely.
1. Check if unit tripped a GCFI outlet or fuse. Try a different
power outlet connection before moving to number 2 on this list.
2. Heating elements can retain some moisture if not used for a
given period of time, or if used in a very humid enviroment. Allow
the unit to heat up for some time to dry out the heat elements.
3. Short in the unit / circuit overload
3. With the unit unplugged, check loose wires and wire terminal
for possible short. Also, check the connections at the ovens’
terminal block in the back for loose wires.
PROBLEM POSSIBLE CAUSE WHAT TO DO BEFORE CALLING TECH. SUPPORT
Quincy Lab, Inc. warrants to the original purchaser that this product will be free from defects in material
and workmanship under normal use throughout the warranty period. The standard warranty period for this
instrument is eighteen months from date of shipment. The instrument warranty is supplemented with a three
year warranty on the heating element. Please refer to your invoice or shipping documents to determine the
active warranty period. This warranty covers parts & labor (labor at factory only) and shipping cost for replacement
parts.
