5
nNote:
• Visit www.AntennaWeb.org to fi nd the location of antennas
in your area.
• To get the best performance from your antenna, select an
indoor fl at surface as high as possible.
• Make sure the antenna is not placed near metal objects
such as cabinets, shelves, refrigerators, a metal door or
wall, or a water pipe behind a wall. Metal objects can
greatly reduce the antenna’s ability to receive signals.
• Higher broadcast frequencies are noticeably affected by
obstructions.
• If your TV has screw terminals for VHF/UHF connection,
connect a 75 to 300-ohm transformer (not supplied)
between the coaxial cable and the VHF/UHF terminals.
• If your TV has a 75-ohm VHF connector and a 300 ohm UHF
connector, connect a signal splitter (not supplied) between
the coaxial cable and the TV’s VHF/UHF connector.
Specifi cations
Power Souce ............................................................120V AC
..........................................................................60 Hz / 6V DC
.......................................................100mA AC / DC Adapter
Frequency Range
VHF .................................................................... 54–216 MHz
UHF ................................................................... 470-806 MHz
FM ....................................................................... 88-108 MHz
Gain .......................................................VHF/UHF 22dB Min
Gain Control ......................................VHF 16dB / UHF 18dB
Output Impedance ..................................................75 ohms
Dimensions .....................7×7.6×4.2 in (24.4×19.5×10.7 cm)
Weight ............................................................11.4 oz (322 g)
Specifi cations are subject to change and improvement without notice.
Actual product may vary from the images found in this document.
