18Getting Started 1335.7346.02 ─ 06

[Pattern Generator] (8)

Connectors for the pattern generator P0, P1, P2, P3.

[Probe Comp.] (8)

Probe compensation terminal to support adjustment of passive probes to the

oscilloscope channel.

Square wave signal for probe compensation.

Ground connector for probes.

[Aux Out] (10)

Multi-purpose BNC output that can function as pass/fail and trigger output, output

for component testing, and as function generator output (with option R&S RTC-

B6).

[USB] type A (11)

USB 2.0 type A interface to connect a USB flash drive for storing and reloading

instrument settings and measurement data, and to update the firmware.

4.2 Rear Panel

Figure 4-2 shows the rear panel of the R&S RTC1000 with its connectors.

On the back panel of the instrument, you find Ethernet and USB interfaces.

Optional interfaces are not available.

Rear Panel
