Chapter 4
14 TM-1 Tilt Module Installation & Reference Manual
Status Indicator
Before contacting a local Raven dealer for support, refer to the following table to help diagnose and correct
possible issues with TM-1 operation.
Note: The LED Status flash pattern consists of a set number of blinks, followed by a pause. The number
of blinks indicates the current status according to the following table.
Status
Indicator
Condition
Status
Corrections
Applied
Corrective Action
0 (Solid
Light)
Normal - OK Yes Indicates valid GPS messages received while moving.
1 Low Speed No
Ensure vehicle speed is above about 2 mph and VTG
messages are enabled.
2 No GPS/GGA No
Ensure GPS receiver is outputting GGA messages.
Ensure serial connector is installed on the GPS input.
Ensure GPS receiver baud rate is between 9600 and 57600
baud.
3 No GPS/VTG No
Ensure GPS receiver is outputting VTG message.
Ensure serial connector is installed.
Ensure GPS receiver baud rate is between 9600 and 57600
baud.
4 EEPROM No Cycle power several times.
5 Over-range No
Cycle power to unit.
Zero Sensor Out.
6 Bypass No Cycle power to unit.
