1.Startingatthebottomcentre,affixthegaskettapetotheMFD.
2.Removethepaperbackingfromthetapebeforegoingaroundthecorners,ensuringthatthetape
remainstortandnoairgapexistsbetweenMFDandtape.
3.Whenyoureachtheend,leaveasmalloverlaptoensurethatnogapexistsbetweentheendsof
thegasketwhenitiscompressed.
Note:Thesuppliedgaskettapeprovidesasealbetweentheunitandasuitablyflatandstiff
mountingsurfaceorbinnacle.Thegasketshouldbeusedinallinstallations.Itmayalsobe
necessarytouseamarine-gradesealantifthemountingsurfaceorbinnacleisnotentirelyflat
andstifforhasaroughsurfacefinish.
Mounting
AxiomXLMFDscanbesurfaceorflushmountedfromtherearofthemountingsurface.
Installation23
