Raymarine AXIOM XL 16 User Manual

4.4NMEA0183connection
NMEA0183devicescanbeconnectedtoyourMFDusingtheNMEA0183wiresonthesupplied
Power/Video/NMEA0183cable.
2NMEA0183portsareavailable:
•Port1:Inputandoutput4,800or38,400baudrate.
•Port2:Inputonly4,800or38,400baudrate.
Note:
•TheBaudrateforeachportmustbesetinyourMFD’ssettings,refertotheoperationinstructions
foryourMFDfordetailsonspecifyingbaudrate.
•ForPort1,boththeinputandoutputcommunicateatthesamebaudrate.Forexample,ifyou
haveoneNMEA0183deviceconnectedtoPort1INPUT,andanotherNMEA0183device
connectedtoPort1OUTPUT,bothNMEAdevicesmustusethesamebaudrate.
Upto4devicescanbeconnectedtothedisplay'soutputportandupto2devicestothedisplay's
inputports.
ItemDeviceCablecolorPort
Input/
output
Positive(+)/
negative(-)
1White1InputPositive
2Green
1InputNegative
3
Y ellow1
Output
Positive
4Brown1
Output
Negative
5
Orange/White
2
InputPositive
6
MFD
Orange/Green
2
InputNegative
7
**Output
Positive
8**Output
Negative
9**
InputPositive
10
NMEAdevice
**
InputNegative
11
**Output
Positive
12
NMEAdevice
**Output
Negative
Note:
*RefertoinstructionsprovidedwithyourNMEA0183deviceforconnectiondetails.
36

Raymarine AXIOM XL 16 Specifications

General

Display Size	16 inches
Display Type	LCD
Brightness	1000 nits
Touchscreen	Yes
Waterproof Rating	IPX6
Operating Temperature	-15°C to 55°C
Operating System	LightHouse 3
Radar Support	Yes
Sonar Support	Yes
Chartplotter	Yes
GPS	Yes
Resolution	1920 x 1080
Video Input	HDMI
Processor	Quad-core processor
Networking	Wi-Fi, Ethernet
Mounting	Flush or bracket
