4.14Analogvideo(Video2)connection
AnalogvideosourcessuchasaThermalorsecuritycameracanbeconnectedtoyourMFDusing
theBNCconnectoronthesuppliedPower/Video/NMEA0183cable.Y ourMFDwillNOTstreamthis
feedovertheSeaTalkhs®network.
1.Power/Video/NMEA0183cablesuppliedwithyourMFD.
2.Analogvideodevice.
3.(Video2)AnalogvideoBNCconnector.
Forinstallationdetails,refertothedocumentationprovidedwithyouranalogvideodevice.
Note:
TheHDMIinandVideo2analogconnectionssharehardwareinternaltotheMFDandsocannot
beusedatthesametime.IfdevicesareconnectedtobothconnectionsthentheHDMIin
connectionwilltakepriority.
48
