Raymarine CP570 User Manual

9
.3CP570Technicalspecification
Physicalspecification
Dimensions•Width:352.5mm(13.9in).
•Height:248.
1mm(9.8in).
•Height(includingconnectors):328.1mm
(12.9in).
•Depth:109.9mm(4.3in).
W eight
6.35kg(14.0lbs)
P owerspecification
Nominalsupplyvoltage
12V/24Vdc
Operatingvoltagerange
10 .8Vto31.2Vdc
P owerconsumption
30.6W(Maximum)
Current3ARMS
Fuse/break ers
5A
Environmentalspecification
Operatingtemperature
–20°C(–4°F)to+50°C(122°F)
S toragetemperature
–30°C(22°F)to+70°C(158°F)
R elativehumidity
95%
W aterproofrating
IPX6
CHIRPSonarspecification
Frequency
25kHzto255kHz
P oweroutput
Upto2KWperchannel(maximum)(total4KW)
Depth
0 .6m(2ft)(to3000m(10,000ft)(Dependantuponconnected
transducer)
T ransducerTransom-mount,in-hull,thru-hull
Connections
•1xP owerconnection
•1xnetworkconnection(RayNetconnector)10/100Mb/s
•1xTransducerconnection
Conformancespecification
Conformance•EN60945:2002
•EMCDirective2014/30/EU
•A
ustraliaandNewZealand:C-Tick,
ComplianceLevel2
90

Raymarine CP570 Specifications

General

Brand	Raymarine
Model	CP570
Category	Sonar
Language	English
