2.3Productoverview
TheHV-300THseriestransducersareHyper
Vision™thru-hullplastictransducers.Y ourinstallation
mustincludeeitherasingleHV-300TH,orasplit-pairofHV-300THP-P(Port)andHV-300THP-S
(Starboard).ThetransduceriscompatiblewithHyperVision™variantdisplays.
Note:
Plasticthru-hulltransducersarerecommendedforfiberglassandmetalhullsandshouldnotbe
usedonvesselswithwoodenhulls.
Thetransducerhasa0°tiltedelement.Thesuppliedfairingblockshouldbecuttomatchthedead
riseangleofyourhull.
Hyper Vision™transducersarecapableofproducingsonarimagesfor:
•RealVision™3D(Hyper1.2MHz)
•RealVision™3D(Standard350kHz)
•SideVision™(Hyper1.2MHz)
•SideVision™(Standard350kHz)
•DownVision™(Hyper1.2MHz)
•DownVision™(Standard350kHz)
•ConicalhighCHIRP(200kHz)
