RDR1520 Series Professional Digital Two-Way Radio Instruction Manual
10
Attaching / Removing the Belt Clip
Using a small screwdriver, align the belt clip’s
screw holes to the radio’s chassis. Attach by
turning the screws clockwise into the belt clip’s
screw holes. Remove by doing the reverse.
(See Figure 5)
Figure 5
Connecting Audio Accessories
The accessory connector is located on the side
of the radio. It is used to connect RCA audio
accessories to the radio. Remove the accessory
cover by unscrewing the screw location at
the bottom of the cover. Connect the desired
audio accessory rmly into the accessory jack
and secure the screw by turning it clockwise.
(See Figure 6)
Figure 6
Note: Please loosen the
screw prior to removing
the audio accessory.
The use of the audio
accessory may affect
the waterproof
performance of
the radio.
