1 PRODUCT FUNCTION

1.7 Error Codes

In the event of a fault with the unit, installation, either battery or solar panel,

both the External LED and ALL the LEDs on the unit will ﬂ ash to indicate the

fault type. Flashing sequences are described in the table below.

LED State Description

1 ﬂ ash (1 ﬂ ash followed by 3.5 second off) Internal Hardware Fault

2 ﬂ ash (2 ﬂ ash followed by 3.5 second off) Reserved

3 ﬂ ash (3 ﬂ ash followed by 3.5 second off) Unit over temp fault

4 ﬂ ash (4 ﬂ ash followed by 3.5 second off) Output Battery Fault (Volts too high)

5 ﬂ ash (5 ﬂ ash followed by 3.5 second off) Input under voltage (Battery)

6 ﬂ ash (6 ﬂ ash followed by 3.5 second off) Input over voltage (Battery or Solar panel)

7 ﬂ ash (7 ﬂ ash followed by 3.5 second off) Reverse polarity

NOTE: The unit will operate optimally below 55°C with good airﬂ ow. At higher

temperatures the unit will de-rate output current.

NOTE: Appropriate connections must be made to the wires with a continuous current

rating of at least 25A. Failure to do so may cause damage to the unit and vehicle.

2 INSTALLATION

1 Mount the unit to a ﬂ at surface close to the auxiliary battery and away from any

heat sources.

2 Wire into vehicle as per the applicable diagram on the next pages, and following

the steps below.

The BCDC1225 is connected using 6 wires, listed below:

• Source Select Blue

• Battery Type Orange

• Remote Indicator Green

• Input Battery Positive Red 40A/30A* Fuse (not supplied)

• Common Ground Black

• Output Battery Positive Brown 40A Fuse (not supplied)

* Current rating is for 24V input voltage.
