Air
Accessories
RGPQ Series
9
EXTERNAL BOTTOM FILTER RACK: RXGF-CB
EXTERNAL SIDE RETURN FILTER RACK: RXGF-CA
†Filter racks are shipped without filters.
Filters shipped with furnace may be used or a suitable 1" [25.4 mm] filter.
*Designates “E” or “N”.
OPTION CODE FOR HIGH ALTITUDE: 278
CANADA-For high altitude derate procedure, refer to furnace
Installation Instructions
RXPF-F01 and F02
FOSSIL FUEL KIT—is for use with Rheem Heat Pumps and
warm air furnaces. RXPF-F02 meets TVA requirements.
ACCESSORY RETURN
AIR CABINETS
Return Air Cabinets may
be installed on either side
application except RXGR-C24B
(side application must be
on side opposite gas and
electrical connections).
THE RXGR-C24B MUST ONLY BE INSTALLED ON THE SIDE
OPPOSITE THE GAS AND ELECTRICAL CONNECTIONS.
WARNING: IMPORTANT NOTICE
A SOLID METAL BASE PLATE (SEE TABLE) MUST BE IN PLACE WHEN THE FURNACE IS
INSTALLED WITH SIDE AIR RETURN DUCTS. FAILURE TO INSTALL A BASE PLATE COULD
CAUSE PRODUCTS OF COMBUSTION TO BE CIRCULATED INTO THE LIVING SPACE AND
CREATE POTENTIALLY HAZARDOUS CONDITIONS.
FURNACE BASE
WIDTH
SOLID BOTTOM BASE
PLATE SIZE
IN. [mm]
KIT NO. PLATE NO.
IN. [mm]
14 [356] RXGB-D14 AE-61874-01 11
5
/8 x 23
9
/16 [295 x 598]
17
1
/2 [445] RXGB-D17 AE-61874-02 15
1
/8 x 23
9
/16 [384 x 598]
21 [533] RXGB-D21 AE-61874-03 18
5
/8 x 23
9
/16 [473 x 598]
24
1
/2 [622] RXGB-D24 AE-61874-04 25
5
/8 x 23
9
/16 [651 x 598]
RETURN AIR CABINETS
A
IN. [mm]
FILTER SIZE
IN. [mm]
RXGR-C24B
24
1
/2
[622]
(2) 24 x 16 [610 x 406]
RXGR-C14B 14 [356] (2) 12 x 16 [305 x 406]
RXGR-C17B
17
1
/
2 [445] (2) 12 x 16 [305 x 406]
RXGR-C21B
21 [533]
(2) 20 x 16 [508 x 406]
FILTER RACK FILTER SIZES† INCHES [mm]
10*BRJ
MODEL
RGPQ-
RXGF-CA
(SIDE)
05, 07, 10*A
15
3
/
4 x 25
[400 x 635]
15
3
/4 x 25
[400 x 635]
12, 15
15
3
/4 x 25
[400 x 635]
[ ] Designates Metric Conversions
