TM031 Integrity 18, 20, 24, 26L Service Instructions REV: B
D.O.I: February 2008
This document is stored and maintained electronically by Service. All printed copies not bearing this statement in RED are deemed “uncontrolled”
Exploded View 1 Replacement Parts List – 871024 Models
Proportional Gas Flow Regulating Valve
Lower Burner Assembly – NG
Lower Burner Assembly – LP
Burner Change-Over Assembly
Water Inlet Connector Assembly (¾)
Water Drain Valve Assembly (includes water filter)
Heat Exchanger and Combustion Chamber Kit
Combustion Chamber Front Panel Assembly
Hot water Outlet Connector (¾)
Over Heat Limiter Assembly
Truss Gasket Screw 4 x 10
*When installed in an 871024, 871024-B or 871024-C model heater these parts will require the
replacement of other interconnecting components. Refer to „Product Changes‟ on page 10 and
„Parts Replacement Scenarios‟ on page 11 for more information.
To Next Page
