TM031 Integrity 18, 20, 24, 26L Service Instructions REV: B
D.O.I: February 2008
This document is stored and maintained electronically by Service. All printed copies not bearing this statement in RED are deemed “uncontrolled”
75
Exploded View 6 Replacement Parts List - 871024-C, 871026 & 871026-B Models
Fitted with solenoid operated bypass
Item No
Description
871026
871026-B
871024-C
133
Silicone Tube (Insulator)
20-43376-00
134
Silicone Tube (Insulator)
20-43376-00
705
Anti-Frost Heater (Heater A)
31-71644-00
706
Anti-Frost Heater Assembly (Heater B)
31-71643-00
708
Anti-Frost Heater Clamp
WH0020049
710
Anti-Frost Heater “C” Clamp (for Heater A)
WH0020050
711
Anti-Frost Heater Clamp (for Heater B)
WH0020051
712
Ambient Air Temp Thermistor Assembly
N/A use *31-76655-00
713
Outlet Thermistor (Thermistor B)
*20-64774-00
714
Anti Frost Thermostat Assembly
20-57072-00
715
Heat Exchanger (HX) Thermistor
N/A use *31-76655-00
716
O-ring – Thermistor
WH0020055
717
Inlet Thermistor (Thermistor A)
*20-64773-00
723
Hall Effect I.C. Assembly
*20-43805-00
728
Combustion Fan
WH0020057
729
Fan Case Assembly
10-88629-00
735
Ignition Pack
31-76722-00
737
Flame Sensor Loom
31-76721-00
745
PCB Assembly
31-76623-0S
751
Gas Type Connector – NG
31-76581-00
31-76592-00
Gas Type Connector - LP
31-76582-00
31-76591-00
757
100 volt loom
31-76653-00
758
Signal Loom (inc amb air & HX thermistor)
*31-76655-00
768
Terminal Block Assembly
WH0020068
771
Noise filter holder assembly
31-23360-00
773
Power filter
*31-71642-00
775
Fuse – In line Note: PCB fuses not fitted
WH0020069
780
Power Cord With Clamp
*31-76652-00
781
Clamp – Power Cord
WH0020072
783
240 -110 Volt Transformer Assembly
*31-71646-00
784
Connecting cord
*31-71641-00
Not Shown
Gas Conversion
- LP to NG
Lower Burner Assy
31-76241-00
Gas Type Connector
31-76581-00
31-76592-00
Nozzle Plate
31-01872-00
31-67238-00
Nozzle Plate Bind Screw
(3 required)
09-46131-00
Not Shown
Gas Conversion
- NG to LP
Lower Burner Assy
31-76240-00
Gas Type Connector
31-76582-00
31-76591-00
*When installed in 871024-C, 871026 & 871026-B model heaters these parts will require the
replacement of other interconnecting components. Refer to „Product Changes‟ on page 10 and
„Parts Replacement Scenarios‟ on page 11 for more information.
Note: For controller and controller cable part numbers refer to page 20.
