Rheem CRITERION II PLUS 2 LXE RGPL- SERIES User Manual

2 Rheem Manufacturing Company
Direct Spark Ignitor
Remote Sensor
In-Shot Burners
Integrated
Furnace Controls
Heat Exchanger
Two-Speed Draft
Inducer Motor
ECM Motor
The complete terms of limited and other warranties are available at our
sales office, or through local installer.
All models can be converted by a qualified Rheem distributor or local service
dealer to use L.P. (propane) gas without changing burners. Factory approved
kits must be used to convert from natural to L.P. (propane) gas and may be
ordered as optional accessories from a Rheem parts distributor.
For L.P. (propane) operation, refer to Conversion Kit Index Form.
WARNING
THIS FURNACE IS NOT APPROVED
OR RECOMMENDED
FOR USE IN MOBILE HOMES
STANDARD EQUIPMENT
Completely assembled and wired; 2 speed draft inducer; high and low pressure
switches; redundant 2 stage main gas control; blower compartment door safety
switch; solid state time on/time off blower control; limit control; transformer;
direct drive multi-speed blower motor. Furnaces are equipped with
cooling/heating relay and transformer (40VA) ready for air conditioning
applications. (Please note: a thermostat is not included as standard equipment.)
Flame sensor diagnostics; fused protection (secondary), 3rd speed fan option
for continuous fan.
OPTIONAL EQUIPMENT
Side filter frame assembly. Return air cabinet for all sizes. (See Page 6)
NOTE: Furnace is not listed for use with fuels other than natural or L.P.
(propane) gas.
RHEEM CRITERION II PLUS 2 LXE
TWO STAGE 80%
UPFLOW/HORIZONTAL GAS FURNACE
