Performance Data @ AHRI Standard Conditions – Cooling (con’t.)
R801T Furnace Ratings
Outdoor
Unit
Furnace Indoor Coil
Total Capacity
BTU/H [kW]
Net Sensible
BTU/H [kW]
Net Latent
BTU/H [kW]
SEER EER
Indoor CFM
[L/s]
AHRI#
RA1318AJ1 R801TA050314MSA
RCF2414STAM 18100 [5.3] 13100 [3.8] 5000 [1.5] 14.5 12 625 [295.0] 7507407
RCF2417HTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 625 [295.0] 7507409
RCF2417MTAM 18000 [5.3] 12800 [3.8] 5200 [1.5] 14.5 12 625 [295.0] 7507424
RCF2417STAM 18000 [5.3] 13500 [4.0] 4500 [1.3] 14.5 12 625 [295.0] 7507440
RA1318AJ1 R801TA075317ZSA
RCF2417HTAM 18300 [5.4] 13200 [3.9] 5100 [1.5] 14.5 12 650 [306.8] 7507410
RCF2417MTAM 18300 [5.4] 13200 [3.9] 5100 [1.5] 14.5 12 650 [306.8] 7507425
RCF2417STAM 18300 [5.4] 13900 [4.1] 4400 [1.3] 14.5 12 650 [306.8] 7507441
RCF2421MTAM 18300 [5.4] 13200 [3.9] 5100 [1.5] 14.5 12 650 [306.8] 7507473
RA1324AJ1 R801TA050314MSA
RCF2414STAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14.5 12 800 [377.6] 7507611
RCF2417HTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14.5 12 875 [413.0] 7507613
RCF2417MTAM 24200 [7.1] 17500 [5.1] 6700 [2.0] 14.5 12 850 [401.2] 7507631
RCF2417STAM 24200 [7.1] 18300 [5.4] 5900 [1.7] 14 11.5 825 [389.4] 7507650
RA1324AJ1 R801TA075317ZSA
RCF2417HTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507614
RCF2417MTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507632
RCF2417STAM 24200 [7.1] 18400 [5.4] 5800 [1.7] 14 11.5 850 [401.2] 7507651
RCF2421MTAM 24400 [7.2] 17700 [5.2] 6700 [2.0] 14 11.5 875 [413.0] 7507692
RA1330AJ1 R801TA050314MSA RCF3617STAM 28800 [8.4] 22000 [6.4] 6800 [2.0] 14 11.5 1000 [471.9] 7507847
RA1330AJ1 R801TA075317ZSA
RCF3617STAM 28400 [8.3] 21200 [6.2] 7200 [2.1] 14 11.5 875 [413.0] 7507848
RCF3621MTAM 30800 [9.0] 23200 [6.8] 7600 [2.2] 14.5 12 1075 [507.3] 7507865
RCF3621STAM 28400 [8.3] 21200 [6.2] 7200 [2.1] 14 11.5 875 [413.0] 7507896
RA1330AJ1 R801TA075417MSA
RCF3617STAM 29000 [8.5] 22200 [6.5] 6800 [2.0] 14 11.5 1000 [471.9] 7507849
RCF3621MTAM 30800 [9.0] 23100 [6.8] 7700 [2.3] 14.5 12 1050 [495.5] 7507866
RCF3621STAM 29200 [8.6] 22500 [6.6] 6700 [2.0] 14 11.5 1025 [483.7] 7507897
RA1330AJ1 R801TA075521ZSA
RCF3621MTAM 30600 [9.0] 22700 [6.7] 7900 [2.3] 15 12.5 1000 [471.9] 7507867
RCF3621STAM 29000 [8.5] 22100 [6.5] 6900 [2.0] 14 11.5 975 [460.1] 7507898
RCF3624HTAM 31200 [9.1] 23000 [6.7] 8200 [2.4] 15.5 13 1025 [483.7] 7507927
RCF3624MTAM 30600 [9.0] 22700 [6.7] 7900 [2.3] 15 12.5 1000 [471.9] 7507951
RA1330AJ1 R801TA100521MSA
RCF3621MTAM 30800 [9.0] 23100 [6.8] 7700 [2.3] 15.1 12.5 1050 [495.5] 7507868
RCF3621STAM 29000 [8.5] 22200 [6.5] 6800 [2.0] 14 11.5 1000 [471.9] 7507899
RCF3624HTAM 31800 [9.3] 24000 [7.0] 7800 [2.3] 15.5 13 1100 [519.1] 7507928
RCF3624MTAM 30800 [9.0] 23100 [6.8] 7700 [2.3] 15.1 12.5 1050 [495.5] 7507952
RA1330AJ1 R801TA100521ZSA
RCF3621MTAM 30600 [9.0] 22600 [6.6] 8000 [2.3] 15.1 12.5 975 [460.1] 7507869
RCF3621STAM 29000 [8.5] 22100 [6.5] 6900 [2.0] 14 11.5 975 [460.1] 7507900
RCF3624HTAM 31200 [9.1] 23000 [6.7] 8200 [2.4] 15.5 13 1025 [483.7] 7507929
RCF3624MTAM 30600 [9.0] 22600 [6.6] 8000 [2.3] 15.1 12.5 975 [460.1] 7507953
RA1330AJ1 R801TA125524ZSA
RCF3624HTAM 31200 [9.1] 22900 [6.7] 8300 [2.4] 15.5 13 975 [460.1] 7507930
RCF3624MTAM 30200 [8.9] 22000 [6.4] 8200 [2.4] 15 12.5 925 [436.6] 7507954
RA1336AC1 R801TA050314MSA RCF3617STAM 35000 [10.3] 24700 [7.2] 10300 [3.0] 13.5 11.5 1000 [471.9] 7508192
RA1336AC1 R801TA075317ZSA
RCF3617STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508193
RCF3621MTAM 38000 [11.1] 27300 [8.0] 10700 [3.1] 14 11.5 1250 [589.9] 7508210
RCF3621STAM 35000 [10.3] 25000 [7.3] 10000 [2.9] 13.5 11.5 1050 [495.5] 7508241
RA1336AC1 R801TA075417MSA
RCF3617STAM 36000 [10.6] 26800 [7.9] 9200 [2.7] 13.5 11.5 1225 [578.1] 7508194
RCF3621MTAM 38000 [11.1] 27100 [7.9] 10900 [3.2] 14.5 12 1200 [566.3] 7508211
RCF3621STAM 36000 [10.6] 26900 [7.9] 9100 [2.7] 13.5 11.5 1250 [589.9] 7508242
RA1336AC1 R801TA075521ZSA
RCF3621MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508212
RCF3621STAM 35800 [10.5] 26300 [7.7] 9500 [2.8] 13.5 11.5 1175 [554.5] 7508243
RCF3624HTAM 38000 [11.1] 26200 [7.7] 11800 [3.5] 15.1 12.5 1025 [483.7] 7508272
RCF3624MTAM 37200 [10.9] 25300 [7.4] 11900 [3.5] 14.5 12 1000 [471.9] 7508299
[ ] Designates Metric Conversions
