21
Injector & Heater Pump Comparison
Heater
Model
Heater Pump Injector Pump
Flow
GPM (lpm)
Temp. Rise
ºF (ºC)
Press. Drop
Ft. hd. (kPa)
Pump Model/
Imp.
Flow
GPM (lpm)
Temp. Rise
ºF (ºC)
Pump
Model-HP
302C 32 (121.1) 16 (8.9) 2 (6.0)
112
13 (49.2) 40 (22.2) 1911-1⁄4
402C 34 (128.7) 20 (11.1) 2 (6.0) 112 17 (64.4) 40 (22.2) 1911-1⁄4
502C 42 (159.0) 20 (11.1) 2.3 (6.9) 1630/4.0 22 (83.3) 40 (22.2) 1911-1⁄4
652C 55 (208.2) 20 (11.1) 4.1 (12.3) 1630/4.0 28 (106.0) 40 (22.2) 1911-1⁄4
752C 63 (238.5) 20 (11.1) 5.7 (17.0) 1630/4.2 32 (121.1) 40 (22.2) 1911-1⁄4
902C 76 (287.7) 20 (11.1) 8.4 (25.1) 1630/4.2 38 (143.8) 40 (22.2) 1911-1⁄4
992C 83 (314.2) 20 (11.1) 5.2 (15.5) 1630/4.7 42 (159.0) 40 (22.2) 1911-1⁄4
1262C 107 (405.0) 20 (11.1) 9.6 (28.7) 1630/4.7 54 (204.4) 40 (22.2) 1911-1⁄3
1532C 120 (454.3) 22 (12.2) 12.4 (37.1) 1632/5.6 62 (234.7) 42 (23.3) 1911-1⁄3
1802C 120 (454.3) 25 (13.9) 13 (38.8) 1632/5.6 68 (257.4) 45 (25.0) 1911-1⁄3
2002C 132 (499.7) 26 (14.4) 19 (56.8) 1634/6.1 74 (280.1) 46 (25.6) 1935-3⁄4
2072C 132 (499.7) 27 (15.0) 19 (56.8) 1634/6.1 75 (283.9) 47 (26.1) 1935-3⁄4
2342C 132 (499.7) 30 (16.7) 21.4 (63.9)
1634/6.1
80 (302.8) 50 (27.8) 1935-3⁄4
Table C. Injector and Heater Pump Specications—Hi Delta
Heater
Model
Heater Pump Injector Pump
Flow
GPM (lpm)
Temp. Rise
ºF (ºC)
Press. Drop
Ft. hd. (kPa)
Pump Model/
Imp.
Flow
GPM (lpm)
Temp. Rise
ºF (ºC)
Pump
Model-HP
503A 58 (219.6) 15 (8.3) 2.4 (7.2)
1611
29 (109.8) 30 (16.7) 1911-1⁄4
753A 63 (238.5) 21 (11.7) 5.6 (16.7) 1611 44 (166.6) 30 (16.7) 1911-1⁄4
1003A 87 (329.3) 20 (11.1) 8.2 (24.5) 1630 58 (219.6) 30 (16.7) 1911-1⁄3
1253A 86 (325.5) 25 (13.9) 12.2 (36.5) 1630 73 (276.3) 30 (16.7) 1911-1⁄3
1503A 100 (378.5) 26 (14.4) 18.5 (55.3) 1632 87 (329.3) 30 (16.7) 1911-1⁄3
1753A 109 (412.6) 28 (15.6) 26 (77.7) 1634 102 (386.1) 30 (16.7) 1911-1⁄3
2003A 116 (439.1) 30 (16.7) 36.2 (108.2)
1636
116 (439.1) 30 (16.7) 1935-3⁄4
Table D. Injector and Heater Pump Specications—MVB
