PHASE*
PHASE*
4.4 ELECTRICAL WIRING
POWER WIRING
• Field wiring must comply with the National Electrical Code (C.E.C. in Canada) and
any applicable local ordinance.
• Supply wiring must be 75°C minimum copper conductors only.
• See electrical data for product Ampacity rating and Circuit Protector requirement.
GROUNDING
• This product must be sufficiently grounded in accordance with National Electrical
Code (C.E.C. in Canada) and any applicable local ordinance.
• A grounding lug is provided.
15
4.5A Electrical Data – Blower Motor Only – No Electric Heat: (-)HSL
HPMODEL VOLTAGE HERTZ RPM SPEEDS
CIRCUIT
AMPS.
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
CIRCUIT
PROTECTOR
MODEL
VOLTAGE HERTZ HP RPM SPEEDS
CIRCUIT
AMPS.
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
CIRCUIT
PROTECTOR
4.5B Electrical Data – Blower Motor Only – No Electric Heat: (-)HLL
4.5 ELECTRICAL DATA – BLOWER MOTOR ONLY – NO ELECTRIC HEAT
*Blower motors are all single phase motors.
1817 1/5 1075 2 2.3 3.0 15
2417 1/5 1075 2 3.8 5.0 15
3017
115 1 60
1/4 1075 2 4.7 6.0 15
3617 1/3 1075 2 6.1 8.0 15
4221 1/2 1075 2 7.9 10.0 15
4821 3/4 1075 2 8.4 11.0 15
1817 1/5 1075 2 1.7 3.0 15
2417 1/5 1075 2 1.7 3.0 15
3017
208/240 1 & 3 60
1/4 1075 2 2.5 4.0 15
3617/3621 1/3 1075 2 2.5 4.0 15
4221 1/2 1075 2 5.2 7.0 15
4821/4824 3/4 1075 2 5.2 7.0 15
6024 208/240 3 60 3/4 1075 2 5.2 7.0 15
3617 1/3 1075 2 1.4 2.0 15
4221
480 3 60
1/2 1075 2 2.2 3.0 15
4821/4824 3/4 1075 2 2.2 3.0 15
6024 3/4 1075 2 2.2 3.0 15
2417 1/3 300-1100 4 1.6 2 15
3617/3621 1/2 300-1100 4 2.8 4 15
208/240 1 & 3 60
3821/4821/4824 3/4 300-1100 4 4.0 5 15
6024 3/4 300-1100 4 4.6 6 15
2417 1/3 300-1100 4 4.8 6 15
3617/3621 1/2 300-1100 4 6.8 9 15
115 1 60
3821/4821/4824 3/4 300-1100 4 9.3 11 15
6024 3/4 300-1100 4 9.3 11 15
6024 480 3 60 3/4 300-1100 4 3.2 4.0 15
