Rheem RHSL-HM4221AA User Manual

19
4.6B ELECTRICAL DATA – WITH ELECTRIC HEAT: (-)HLL
RXBH-1724?03J 2.25/3.0 1/60 1-3.0 SINGLE 10.8/12.5 1.6 16/18 20/20
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 1.6 24/27 25/30
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 1.6 35/40 35/40
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 1.6 46/52 50/60
(-)HLL RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 1.6 59/68 60/70
2417 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 1.6 21/24 25/25
RXBH-1724A13J
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0 38/44 40/45
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 1.6 21/24 25/25
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 1.6 27/31 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 1.6 35/40 35/40
RXBH-1724?03J 2.25/3.0 1/60 1-3.0 SINGLE 10.8/12.5 2.8 19/20 20/20
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 2.8 26/29 30/30
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 2.8 36/41 40/45
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 2.8 47/54 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 2.8 60/69 60/70
3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 2.8 23/26 25/30
(-)HLL
RXBH-1724A13J
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0 38/44 40/45
3617 RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 2.8 69/79 70/80
3.6/4.8 1/60 1-4.8 MULTIPLE CKT 1 17.3/20.0 2.8 26/29 30/30
RXBH-1724A15J
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
RXBH-1724A18J 12.8/17.0 1/60 3-5.68 SINGLE 61.6/70.8 2.8 81/92 90/100
4.3/5.7 1/60 1-5.68 MULTIPLE CKT 1 20.5/23.6 2.8 29/33 30/35
RXBH-1724A18J
8.5/11.3 1/60 2-5.68 MULTIPLE CKT 2 41.1/47.2 0 52/59 60/60
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 2.8 23/26 25/30
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 2.8 29/33 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 2.8 37/42 40/45
RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 2.8 41/47 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-5.68 SINGLE 35.5/41.0 2.8 48/55 50/60
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 4.0 27/30 30/30
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 4.0 38/43 40/45
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 4.0 49/53 50/60
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 4.0 70/80 70/80
3.6/4.8 1/60 1-4.8 MULTIPLE CKT 1 17.3/20.0 4.0 27/30 30/30
RXBH-1724A15J
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17.0 1/60 4-4.26 SINGLE 61.6/70.8 4.0 82/94 90/100
6.4/8.5 1/60 2-4.26 MULTIPLE CKT 1 30.8/35.4 4.0 44/50 45/50
RXBJ-1724A18J
6.4/8.5 1/60 2-4.26 MULTIPLE CKT 2 30.8/35.4 0.0 39/45 40/45
(-)HLL RXBH-24A20J 14.4/19.2 1/60 4-48 SINGLE 69.2/80 4.0 92/105 100/110
4821 7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.0 49/55 50/60
RXBH-24A20J 7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.0 113/130 125/150
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 1 28.8/33.3 4.0 41/47 45/50
RXBH-24A25J
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0.0 36/42 40/45
(4-ton only)
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 3 28.8/33.3 0.0 36/42 40/45
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 4.0 24/27 25/30
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 4.0 30/34 30/35
RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 4.0 43/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-2.84 SINGLE 35.6/41.0 4.0 50/57 50/60
RXBH-24A20C* 14.4/19.2 3/60 3-3.2 SINGLE 40.0/46.2 4.0 55/63 60/70
7.2/9.6 3/60 3-3.2 MULTIPLE CKT 1 20.0/23.1 4.0 30/34 30/35
RXBH-24A20C
7.2/9.6 3/60 3-3.2 MULTIPLE CKT 2 20.0/23.1 0.0 25/29 25/30
RXBH-24A25C* 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.0 68/77 70/80
RXBH-24A25C
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.0 37/42 40/45
(4-ton only)
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0.0 32/37 35/40
AIR HANDLER
MODEL
HEATER
MODEL
NO.
HEATER
KW
(208/240V)
(480V)
PH/HZ
NO.
ELEMENTS
- KW PER
TYPE SUPPLY
CIRCUIT
SINGLE CIRCUIT
MULTIPLE CIRCUIT
CIRCUIT
AMPS.
MOTOR
AMPACITY
MINIMUM
CIRCUIT
AMPACITY
MAXIMUM
CIRCUIT
PROTECTION
Installation of the UL Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
? Heater Kit Connection Type A=Breaker B=Terminal Block C=Pullout Disconnect
