28
INSTALLATION – SOLAR CONTROL UNIT
The solar control unit is designed to be mounted on the side of the solar storage tank, with its location above
and offset from the solar cold water outlet. The solar control unit, supplied with a 1.8 metre power cord,
requires a 240 V 50 Hz general purpose outlet (GPO) located within 1.2 metres of its installation. The GPO
must have a continuous power supply originating from a circuit other than the water heater circuit. The GPO
is required to be weatherproof if installed outdoors (refer to “Connections – Electrical” on page 38).
Kit Components and Description - Controller Kit
Installation instructions solar controller kit
Control unit solar pumped assembly
Valve assembly air bleed and check
consisting of:
1 x 088058 fitting tee brass ½” screwed Rye 4203
1 x 088071 solar non return valve RMC ½” x ¾” SNR502
1 x 088069 fitting adaptor brass 1” F x ½” M
1 x 220340 air bleed ball valve
1 x 080123 washer 30 OD x 20 ID x 2 Salmson
Sensor tee / nipple assembly solar pumped
consisting of:
1 x 088061 tee 3 way / cold sensor
1 x 088062 sensor nipple – solar pumped
1 x 087026 O ring 5/16” ID x 1/16” BS011 silicone
Pipe preformed tube ½” x 240 mm long
Fitting union male ½” x ½” Rye 4910
Fitting nipple brass ¾” x ½”
Cable tie black 150 mm x 3 mm
Insulation pipe 12 mm ID x 400 mm long
Insulation pipe 35 mm ID x 150 mm long
Insulation pipe 35 mm ID x 50 mm long
Notes:
Care must be taken when mounting the solar control unit to the side of the solar storage tank. Damage
to the cylinder as a result of mounting the solar control unit to the jacket will void the warranty (refer to
“Saddling - Pipe Work” on page 25).
Use thread sealing tape or an approved thread sealant on all fittings.
