18. [Check Status] key
Press to check the machine's system status, operational status of each function, and current jobs. You can also
display the job history and the machine's maintenance information.
19. Data In indicator (facsimile and printer mode)
Flashes when the machine is receiving print jobs or LAN-Fax documents from a computer. See Fax and
Print .
20. Communicating indicator, Fax Received indicator, Confidential File indicator
• Communicating indicator
Lights continuously during data transmission and reception.
• Fax Received indicator
Lights continuously while data other than personal box or Memory Lock file is being received and stored
in the fax memory.
See "Substitute Reception", Fax .
• Confidential File indicator
Lights continuously while personal box data is being received.
Blinks while Memory Lock file is being received.
See "Personal Boxes" and "Printing a File Received with Memory Lock", Fax .
21. Media access lamp
Lights up when a removable memory device is inserted in the media slot or accessed.
22. Media slots
Use to insert an SD card or a USB memory.
Guide to the Names and Functions of the Machine's Control Panel
47
