Ricoh Aficio MP C305 User Manual

8. Web Image Monitor
This chapter describes frequently used Web Image Monitor functions and operations. For the
information not included in this chapter, see Connecting the Machine/ System Settings on the
supplied CD-ROM or Web Image Monitor Help.
Displaying Top Page
This section explains the Top Page and how to display Web Image Monitor.
• When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10".
1. Start your Web browser.
2. Enter "http://(machine's IP address or host name)/" in your Web browser's URL bar.
Top Page of Web Image Monitor appears.
If the machine's host name has been registered on the DNS or WINS server, you can enter it.
When setting SSL, a protocol for encrypted communication, under environment which server
authentication is issued, enter "https://(machine's IP address or host name)/".
Web Image Monitor is divided into the following areas:
1
2
3
5
4
CMM004
1. Menu area
If you select a menu item, its content will be shown.
2. Header area
The dialog box for switching to the user mode and administrator mode appears, and each mode's menu will
be displayed.
The link to Help and dialog box for keyword search appears.
121

Ricoh Aficio MP C305 Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	350 sheets
Max Paper Capacity	1350 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Processor	533 MHz
Dimensions	498 x 532 x 505 mm
Print Speed	30 ppm (mono) / 30 ppm (color)
Copy Speed	30 ppm (mono) / 30 ppm (color)
Zoom Range	25% - 400%
Paper Size	A4
Paper Weight	60 – 163 g/m²
Memory	1.5 GB
Interface	USB 2.0
Fax Resolution	200 x 200 dpi
Operating System Compatibility	Windows, Mac, Linux
Display	4.3-inch Color Touch Panel
Scan Speed	30 ipm (images per minute)
