Copying onto Custom Size Paper from the
Bypass Tray
Paper that has a horizontal length of 139.0–600.0 mm (5.48–23.62 inches) and a vertical length of
76.2–216.0 mm (3.00–8.50 inches) can be fed in from the bypass tray. Note however that the
limitation on the horizontal and vertical length range will vary depending on which options are installed.
• When prints are delivered to the internal tray 2:
Horizontal length: 210.0–600.0 mm (8.27–23.62 inches), vertical length: 139.7–216.0 mm
(5.50–8.50 inches)
1. Load the paper face down in the bypass tray.
The bypass tray (
) is automatically selected.
2. Press the [ ] key.
3. Press [Paper Size].
4. Press [Custom Size].
5. Enter the horizontal size with the number keys, and then press [ ].
6. Enter the vertical size with the number keys, and then press [ ].
7. Press [OK] twice.
8. Place the originals, and then press the [Start] key.
Copying onto Custom Size Paper from the Bypass Tray
69
