Ricoh Alex-P1 Technical Bulletin

Technical Bulletin PAGE: 1/4
Reissued:26-Sep-14
Model: AL-C2b
Date: 14-Mar-14
No.: RD129049a
RTB Reissue
The items in bold italics were corrected or added.
Change/Reason: To prevent the cleaning web coming loose, the following parts are
changed and newly added to the fusing unit.
[1] Addition of a variable brake on the cleaning web.
[2] Changed the one-way clutch method to ratchet method on the holder roller.
Old part
number
New part
number
Description
Q’ty
Int
Page
Index
Set
Note
D1294305
D1294304
CLEANING
UNIT:ASS'Y
1
X/O
76
*
AE040099
AE040100
ROLLER:
PLATE
1
X/X
76
9
B
-
D1294331
FLAT NUT:BRAKE
1
76
24**
A
Please refer to [A] for [1]
-
D1294332
BRAKE:WEB
1
76
25**
A
Please refer to [B] for [1]
D0094355
-
ROLLER CLUTCH
76
8
Deleted,
please refer to [C]
-
D1294359
BUSHING:
ROLLER:PLATE:
FRONT
2
X/X
76
26**
B
Please refer to [D] for [2]
-
B0654211
PRESSURE
ROLLER GEAR
1
76
27**
B
Please refer to [E] for [2]
-
B1404209
BRACKET:
STOPPER:ASS'Y
1
76
28**
B
Please refer to [F] for [2]
-
D1294309
BRAKE:WEB:ASS
'Y
1
76
29**
-
D0094321
STAY:UPPER
1
76
30**
・Part number of Fusing Unit doesn’t change.
**: New Index
Subject: Parts change and addition information.
Prepared by: Y.Saitoh
From: 2nd Tech Service Sect., MFP/P Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Product Safety
Part information
Electrical
Transmit/receive
Other ( )
Action required
Service manual revision
Retrofit information
Tier 2
