Ricoh gr digital III User Manual

FIRST-TIME USER? READ THIS.
18
Taking a Photograph
Taking a Photograph
1
Focus.
Frame your subject in the center of the picture dis-
play and press the shutter-release button halfway to
set focus and exposure.
If the camera is unable to focus, the
center focus frame blinks red
and the autofocus/flash lamp
blinks green.
If the camera is able to focus, the
focus frames (up to nine) that
contain objects that are in fo-
cus are shown in green.
Autofocus/flash lamp
Focus frame
2
Take the picture.
Gently press the shutter-release button the rest of
the way down to take the picture. The photograph
you have just taken will be displayed in the picture
display as it is recorded to the memory card or inter-
nal memory.

Ricoh gr digital III Specifications

General

Megapixel	10 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	No
Image sensor size	1/1.7 \
Maximum image resolution	3648 x 2736 pixels
Optical zoom	5.7 x
Fixed focal length	6 mm
Focal length range	- mm
Digital SLR	-
Minimum RAM	256 MB
Built-in flash	Yes
Minimum processor	500 MHz
Camera shutter speed	- s
Minimum storage drive space	160 MB
Compatible operating systems	Windows 2000, XP, Vista; Mac OS9.0-9.2.2, Mac OSX10.1.2-10.5.6.
Auto focusing (AF) modes	Multi Point Auto Focus, Spot Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Flash modes	auto, Flash off, manual, Red-eye reduction, Slow synchronization
Internal memory	88 MB
Compatible memory cards	SD, SDHC
Maximum memory card size	32 GB
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	3 \
Display resolution (numeric)	- pixels
Scene modes	Documents
Image editing	resizing, rotating
White balance	Auto, Cloudy, Daylight, Fluorescent, Incandescent, Manual
Camera playback	Movie
Self-timer delay	10 s
Product color	Black
Battery technology	Alkaline
Number of batteries supported	2

Weight and Dimensions

Depth	25.5 mm
Width	59.8 mm
Height	108.6 mm
