1.Replacement and Adjustment
14
Paper Transport Sensor
1. Pull out the paper tray.
2. Remove the grounding plate and vertical transport cover open/close switch bracket. (Vertical Transport Cover
Open/Close Switch)
3. Remove the paper transport sensor with bracket [A]. ( × 1, × 1, × 1)
4. Remove the paper transport sensor [A]. (Hooks × 3)
