1.
Replacement
and Adjustment
18
V
ertical
T
rans
port Cover Open/Close Switc
h
1.
Open the r
ight door
.
2.
Remove the
upper cover
. (
Upper Cover
)
3.
Remove the
grounding plate [A
] and the
sensor br
acket [B]. (
× 4
,
× 2,
× 1)
4.
Remove the
vertical transport cover
open/close switch [A]. (
Hooks × 2)
21
23
Table of Contents
Table of Contents
5
Replacement and Adjustment
6
Beforehand
6
Rear Cover
7
Upper Cover
8
Controller Board
9
Controller Board with the Bracket
9
Paper Feed Roller
11
Friction Pad
12
Vertical Transport Rollers
13
Vertical Transport Roller (Driven Side)
13
Vertical Transport Roller (Driving Side)
13
Paper End Sensor/ Remaining Paper Sensor
16
Paper Transport Sensor
18
Tray Bottom Plate Lift Sensor and HP Sensor
19
Tray Bottom Plate Lift Sensor
19
Tray Bottom Plate HP Sensor
19
Tray Set Switch
21
Vertical Transport Cover Open/Close Switch
22
Tray Lift Motor
23
Paper Feed Motor
24
Vertical Transport Clutch and Relay Clutch
25
