INSTALLATION
2.6.1 Water-side pressure drop
Model
∆T=20°F ∆T=30°F ∆T=40°F ∆T=60°F
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
(GPM) (psi) (GPM) (psi) (GPM) (psi) (GPM) (psi)
RTC 3000 285 1.56 190 0.86 143 0.58 95 0.34
RTC 4000 380 0.63 253 0.39 190 0.29 127 0.19
RTC 5000 475 0.59 317 0.36 238 0.25 158 0.16
RTC 6000 570 1.24 380 0.76 285 0.54 190 0.35
RTC 8000 760 1.01 507 0.59 380 0.41 253 0.25
RTC 10000 950 0.76 633 0.41 475 0.28 317 0.17
Efciency at 95% full load
Model
∆T=20°F ∆T=30°F ∆T=40°F ∆T=60°F
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
(GPM) (psi) (GPM) (psi) (GPM) (psi) (GPM) (psi)
RTC 3000 276 1.48 184 0.82 138 0.55 92 0.33
RTC 4000 368 0.61 245 0.38 184 0.28 123 0.18
RTC 5000 460 0.56 307 0.34 230 0.25 153 0.16
RTC 6000 552 1.19 368 0.73 276 0.52 184 0.33
RTC 8000 736 0.97 491 0.56 368 0.39 245 0.24
RTC 10000 920 0.72 613 0.39 460 0.27 307 0.16
Efciency at 92% full load
Model
∆T=20°F ∆T=30°F ∆T=40°F ∆T=60°F
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
Flow-rate
Pressure
drop
(GPM) (psi) (GPM) (psi) (GPM) (psi) (GPM) (psi)
RTC 3000 261 1.36 174 0.76 131 0.51 87 0.30
RTC 4000 348 0.57 232 0.36 174 0.26 116 0.17
RTC 5000 435 0.52 290 0.32 218 0.23 145 0.15
RTC 6000 522 1.11 348 0.68 261 0.49 174 0.32
RTC 8000 696 0.90 464 0.52 348 0.36 232 0.22
RTC 10000 870 0.66 580 0.36 435 0.25 290 0.15
Efciency at 87% full load
