2 Multipurpose Knobs 10 Horizontal Controls

3 Analyse Key 11 Vertical Controls

4 Measure Key 12 Probe Compensation Signal

Output Terminal/Ground Terminal

5 Cursor Key 13 Analog Channel Input Terminals

6 Common Tools Keys 14 Digital Channel Input Terminal

7 Touch Lock Key 15 USB HOST Port

8 Quick Action Key (Self-defined

function)

16 Power Key

4.3 Rear Panel Overview

Figure 4.4 Rear Panel

AUX OUT Interface

2 AFG OUT Interface (for DHO914S and DHO924S only)

3 LAN Port

4 USB DEVICE Port

5 HDMI Connector

6 USB Type-C Power Connector

7 Security Lock Hole

8 Ground Terminal

9 Mounting Screws (VESA 100 x 100)

Product Overview
