Type A
Main Zone only
Your lawn area is one continuous zone
and all areas of the lawn are wide
enough for the mower to navigate
through (at least 4 m (14 ft) wide at its
narrowest point).
Understanding your lawn will save you unnecessary
mistakes and make the installation process easier and
more straight-forward.
Know Your Lawn
Main Zone
Main Zone
Sub Zone
Type B
Main Zone + Sub Zone
Your lawn consists of more than one
zone. These zones are connected by
a narrow passage 1-2 m (3-6ft). The
mower can drive between these zones
to mow the entire area.
You can also skip some later sections in this manual that are not relevant to
your lawn type.
So, what does your lawn look like?
