Roborock S5 Max User Manual

Basic parameters
Robot Charging dock
Note:
The serial number is on a sticker on the underside of the robot.
Name Parameters
353×350×96.5mm
Dimensions
14.4V/5200mAh lithium battery
Battery
Approx. 3.5 kg
Weight
WiFi Smart Connect
Wireless connection
58WRated power
Rated voltage
14.4VDC
Name Parameters
151×130×98mmDimensions
S5 Max
Model
CDZ11RR or CDZ12RRModel
28WRated power
100-240VACRated input
Rated output
Rated frequency 50-60Hz
20VDC 1.2A
27
WiFi Specification
Service
WiFi
Protocol
802.11b/g/n
Frequency Range
2400-2483.5 MHz
Max. Output Power
≤20dBm

Roborock S5 Max Specifications

General

Brand	Roborock
Model	S5 Max
Category	Vacuum Cleaner
Language	English
