10 Rockwell Automation Publication 1783-IN011B-EN-P - April 2023
Stratix 2500 Lightly Managed Switches Installation Instructions
Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at http://www.rockwellautomation.com/global/literature-library/overview.page. To order paper copies of technical documentation, contact
your local Allen-Bradley distributor or Rockwell Automation sales representative.
Attribute 1783-LMS5 1783-LMS8
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-20…+60 °C (-4…+140 °F)
Temperature, ambient, max 60 °C (140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure type rating None (open-style)
Power input 12…24V DC, 0.3…0.2A (SELV) 12…24V DC, 0.4…0.2A (SELV)
Wire size, Ethernet connections
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable
according to ISO/IEC 24702
Wire size, functional ground
5.2…3.3 mm
2
(10…12 AWG) solid or stranded copper wire
Wire size, DC power
1.30…0.82 mm
2
(16…18 AWG) solid or stranded copper wire rated at 30 °C (86 °F), or greater, above the surrounding air
temperature
Torque, power terminal screw 0.19 N•m (1.7 in•lb)
Torque, functional ground lug screw 0.51 N•m (4.5 in•lb)
North American temp code T4
ATEX temp code T4
Resource Description
Stratix Ethernet Device Specifications Technical Data, publication 1783-TD002
Provides specification information for Ethernet switches and other devices.
Stratix 2500 Lightly Managed Switches User Manual, publication 1783-UM009
Describes how to configure, monitor, and troubleshoot the switch.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1
Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications
Provides declarations of conformity, certificates, and other certification details.
